Questions fréquemment posées

Comment remplacer ?

  • Step 1: Disconnect the power supply to the motor.
  • Step 2: Remove the existing motor by unbolting it from the mount.
  • Step 3: Install the new motor, aligning it with the mount centers, and secure it with bolts.
  • Step 4: Reconnect wiring: for 115v, connect black to one side of the line and red to the other side; for 230v, connect black to one side and yellow to the other.
  • Step 5: Tie blue and white wires together for both voltage configurations.
  • Step 6: Restore the power supply and test the motor.

Estimer le temps ?

Environ 30 à 45 minutes pour un remplacement complet.

Quels outils sont nécessaires ?

Un jeu de douilles, un tournevis et une pince à dénuder.
